All-Fuel Chimney - 6” to 8” UltimatePlus

6" to 8" All-Fuel Chimney - UltimatePlus

Available in April 2024

UltimatePlus offers the latest technology for hearth professionals. Factory-built design with superior performance, durability and safety.

A professional-grade latching system makes installation simple and quick. No tools required!
Continuous-welded outer and inner seams create a sleek, smooth, clean look.
Stainless Steel inner and outer
Satin Finish
Solid Pack Insulation
No continuous shielding required

UltimatePlus is constructed of superior grades of stainless steel for exceptional strength and corrosion resistance. It comes standard with an inner liner of 304 stainless and an outer casing of Satin Finish 430 stainless. The 6" diameter is also available in a premium 316/304 stainless option. All inner and outer casings have continuous laser-welded seams to seal and protect.

The UltimatePlus includes a proprietary 1" high temperature mineral wool insulation which eliminates the need for continuous shielding. The robust design of the UltimatePlus' joint-securing system integrates a professional, no tool, latch-type locking band for a quick, solid and secure installation every time!

6"–8" Diameter:

304 Stainless Steel Inner Liner, Satin Finish 430 Stainless Outer Casing
Premium option: 6" Only - 316 Stainless Inner Liner, Satin Finish 304 Stainless Outer Casing
All residential fuels
No continuous shields required
1" High Temperature Solid Pack Mineral Wool Insulation
New insulated components
Reduced clearance supports
Universal components
Multiple Support Kits available
Limited Lifetime Warranty on all components

Approvals:

Listed to UL103 TYPE HT in the U.S.A.
Listed to CAN/ULC-629 and CAN/ULC-604 in Canada
On approved appliances listed to UL127 & CAN/ULC-610

UltimatePlus Installation Instructions
